LTS LTD8316M-ET Platinum Professional 16 Channel H.265+ HD-TVI Hybrid (No HDD)

Features:

• Deep learning-based motion detection 2.0 for all analog channels
• Deep learning-based perimeter protection
• H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 video compression
• HDTVI/AHD/CVI/CVBS/IP video inputs
• Audio via coaxial cable
• Up to 24-ch IP camera inputs (up to 6 MP)
• Up to 10 TB capacity per HDD

Specifications:

Motion Detection 2.0¹

• Human/Vehicle Analysis: Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and reduce false alarms caused by objects like leaves and lights
• Quick search by object or event type is supported

Perimeter Protection¹

• Human/Vehicle Analysis: Up to 4-ch

Facial Detection¹

• Facial detection and capture: 1-ch human face capture (HD analog camera)

Recording

• Video compression: H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
• Main stream:
• hen 1080p Lite mode not enabled:
• For 4 MP stream access: 4 MP lite@15 fps; 1080p lite/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N)
• For 3 MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@15 fps
• For 1080p stream access: 1080p/720p@15 fps; VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N)
• For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N)
• When 1080p Lite mode enabled: 4 MP lite/3 MP@15 fps; 1080p lite/720p lite/VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N)
• Sub-stream: WD1/4CIF@12 fps; CIF@25 fps (P)/30 fps (N)
• Video bitrate: 32 Kbps to 6 Mbps
• Dual stream: Support
• Stream type: Video, Video & Audio
• Audio compression: G.711u
• Audio bitrate: 64 Kbps

Video and Audio

IP video input²

• 2-ch (up to 18-ch)
• Enhanced IP mode on: 8-ch (up to 24-ch), each up to 4 Mbps
• Up to 6 MP resolution
• Support H.265+/H.265/H.264+/H.264 IP cameras
• Analog video input: 16-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
• HDTVI input: 4 MP, 3 MP, 1080p@30 fps, 1080p@25 fps, 720p@60 fps, 720p@50 fps, 720p@30 fps, 720p@25 fps
• AHD input: 4 MP, 1080p@25 fps, 1080p@30 fps, 720p@25 fps, 720p@30 fps
• HDCVI input: 4 MP, 1080p@25 fps, 1080p@30 fps, 720p@25 fps, 720p@30 fps
• CVBS input: PAL/NTSC
• CVBS output: 1-ch, BNC (1.0 Vp-p, 75 Ω)
• Resolution: PAL: 704 x 576, NTSC: 704 x 480
• HDMI/VGA output: 1-ch, 1920 x 1080/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz, HDMI/VGA simultaneous output
• Audio input: 1-ch, RCA (2.0 Vp-p, 1 KΩ) 16-ch via coaxial cable
• Audio output: 1-ch, RCA (Linear, 1 KΩ)
• Two-way audio: 1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
• Synchronous playback: 16-ch

Network

• Remote connection: 128
• Network protocol: TCP/IP, PPPoE, DHCP, LTS-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
• Network interface: 1,RJ45 10/100/1000 Mbps self-adaptive Ethernet interface
• Wi-Fi: Connectable to Wi-Fi network by Wi-Fi dongle through USB interface

Auxiliary interface

• SATA: 2 SATA interfaces, up to 10 TB capacity for each disk
• Serial interface: RS-485 (half-duplex)
• USB interface: Front panel: 1 x USB 2.0 Rear panel: 1 x USB 3.0
• Alarm in/out: N/A

General

• Power supply: 12 VDC, 3.3 A
• Consumption (without HDD): ≤ 40 W
• Working temperature: -10 °C to 55 °C (14 °F to 131 °F)
• Working humidity: 10% to 90%
• Dimension: (W x D x H)    380 x 320 x 48 mm (15.0 x 12.6 x 1.9 inch)
